B series multifunction laser rangefinder
The launch of the Onick B series represents a new revolutionary professional level of measurement accuracy. Within the range of 200 meters, accurate measurement is 0.1 meters, no blind spots are 0 meters, and measurement is 0 meters. New measurement vibration reminder function is added, and the longest distance mode! With Bluetooth and RS232 serial ports, it is widely used in the field of power line surveying applications.
€0
Measurement Range: 0-1800m、0-2000m、0-2200m
Product Model: 1800B、2000B、2200B
Product Details
Product Details
Ounika B series rangefinder-Measurement Star, glorious new life!
A major upgrade! Anti-shake rangefinder, accuracy 0.1 meters, no blind spots, 0 meters, new measurement vibration reminder
The launch of the Onick B series represents a new revolutionary professional level of measurement accuracy. Within the range of 200 meters, accurate measurement is 0.1 meters, no blind spots are 0 meters, and measurement is 0 meters. New measurement vibration reminder function is added, and the longest distance mode! With Bluetooth and RS232 serial ports, it is widely used in the field of power line surveying applications. The solid exterior material, comfortable anti-slip rubber, the eyepiece diopter adjustment and smooth rotation, further improving the user experience. It has a built-in 1200 mA lithium charging system, which can be measured about 10,000 times. The Onick B series rangefinder has intuitive, convenient and fast functions to help you carry out your work outdoors more efficiently!
Product Features:
1. High-precision dual display reading data, with an accuracy of 0.1m;
2. Measurement starts from 0 meters without measurement blind spot, with measurement vibration reminder function, maximum distance mode;
3. With RS232 serial port and Bluetooth, you can connect to the APP;
4. Combines the functions of ordinary telescopes and laser rangefinders;
5. Semiconductor safe laser ranging measurement, no cooperation target is required, and any object can be measured;
6. 2D measurement is integrated to meet single measurement, continuous measurement, horizontal distance measurement, vertical height measurement, height difference measurement, and inclination angle measurement;
7. Built-in 1200 mA charging system, which can complete 10,000 measurements;
Areas of application:
Power line selection survey and design, power safety patrol, forestry survey, security and police use, geological exploration, field hunting, railway construction measurement, installation measurement, high-rise building monitoring, high-speed rail dedicated line rail construction, water conservancy and hydropower measurement, water conservancy and river survey, oil pipelines, archaeological research, mine survey, railway line selection, land and resource survey, etc.
| Product Model | 1800B、2000B、2200B |
| Measurement Range | 0-1800m、0-2000m、0-2200m |
| Measurement Accuracy | ±0.2m(<200m) ±1m(>200m) |
| Ranging Display | Built-in and external LCD display |
| Magnification | 7x |
| Objective Diameter | 26mm |
| Field of View | The range is 104m at 6°/1000m |
| Operating Temperature | -10-50ºC |
| Service Temperature | ≤80% |
| Inclination Accuracy | ±1° |
| Exit pupil Diameter | 3.7mm |
| Exit Pupil Distance | 18.8mm |
| Laser Type | FDAClass1CFR21 |
| Focusing Mode | Eyepiece focusing |
| Vibration Reminder | Yes |
| Contour Size | 126x79.5x44mm |
| Weight | 246g |
| Ranging Mode | Common ranging,horizontal distance,vertical distance,height difference |
| Power | 1200MA/H rechargeable lithium battery |
| Tripod | 1/4 inch threaded hole (optional) |
| Data Transmission | With Bluetooth and RS232 serial port |
| Packing List | Range finder, portable bag, USB charging cable, lanyard, mirror cloth, Manual, product manual warranty card, color box |
